download Datenblatt_LED_Feuchtraum_Wannenleuchte___Serie_30___de_en__2026_01.pdf download Datenblatt_LED_Feuchtraum_Wannenleuchte___Serie_30_einstellbar___de_en__2026_01.pdf

Feuchtraum-Wannenleuchten - Serie 30

LED-FR-Wannenl. 30150.47.4 IP66 27-47,5W, 4440-7460lm, 4000K PC opal, 1450x98x91 mm, CRI>80

Width: 98 mm, Length: 1450 mm, Colour temperature: 4000 K, Max. system power: 47 W, Rated luminous flux according to IEC 62722-2- 1: 7460 lm

Product nr.: 30105255-1MW

See all versions

Price for registered users only

As a registered user, you have access to all prices for our items and can order directly.

Log in
Product description Technical specifications Downloads All versions

Product description

Feuchtraum-Wannenleuchte IP66 mit einstellbarer Leistung und opalen,
innen längsprismiertem Diffusor
> Vielseitig verwendbare Leuchte für hohe Anforderungen
 > Schutzart IP66 und hohe Stoßfestigkeit (IK10)
> Einstellbare Lichtstärke für individuelle Anpassung an verschiedene Einsatzbereiche
> Geringe Stromkosten durch modernste LEDTechnik mit überragender Effizienz und Langlebigkeit

Special features

Surface-mounted luminaire

Surface-mounted luminaire

Connected loads 220-240 V, 0-50-60 Hz

Connected loads 220-240 V, 0-50-60 Hz

Connected loads 220-240 V, 50-60 Hz

Connected loads 220-240 V, 50-60 Hz

CE

CE

Color-Rendering-Index CRI-80

Color-Rendering-Index CRI-80

IP-66

IP-66

LED

LED

Luminaire with limited surface temp

Luminaire with limited surface temp

Luminaire with limited surface temp, expect type

Luminaire with limited surface temp, expect type

Pendant

Pendant

Risk group RG-1

Risk group RG-1

Color Consistency SDCM-3

Color Consistency SDCM-3

Sconce

Sconce

Technical specifications

General

ETIM-class:

Ceiling-/wall luminaire

Housing material:

Plastic

Housing colour:

Grey

Material cover:

Plastic, opal

Voltage type:

AC/DC

Type of control gear:

LED operating device current-controlled

Light distributor:

Diffuser lens/optic/panel

Light distribution:

Symmetric

Beam angle:

> 80° - Extreme wide beam

Colour consistency (McAdam ellipse):

SDCM3

Light outlet:

Direct

Degree of protection (IP), front side:

IP66

Impact strength:

IK10

Protection class according to IEC 61140:

I

Filament test according to IEC 60695-2-11:

650 °C - 30 s

Colour rendering index CRI:

80-89

Type of wiring:

Suitable for loop-through wiring

Connection type:

Push-in clamp

Photobiological safety according to EN 62471:

RG1

Colour of light adjustable:

No

Luminous flux adjustable:

No

Beam angle adjustable:

No

Colour temperature:

4000 K

Rated lifetime L70/B50 at 25 °C:

50000 h

Height/depth:

91 mm

Width:

98 mm

Length:

1450 mm

Max. system power:

47 W

Rated luminous flux according to IEC 62722-2- 1:

7460 lm

All versions

Type Colour temperature Width Length Max. system power Rated luminous flux according to IEC 62722-2- 1 Product nr.
Type LED-FR-Wannenl. 30150.47.4 IP66 27-47,5W, 4440-7460lm, 4000K PC opal, 1450x98x91 mm, CRI>80 Colour temperature 4000 K Width 98 mm Length 1450 mm Max. system power 47 W Rated luminous flux according to IEC 62722-2- 1 7460 lm Product nr. 30105255-1MW keyboard_arrow_down
LED-FR-Wannenl. 30150.47.4 IP66 27-47,5W, 4440-7460lm, 4000K PC opal, 1450x98x91 mm, CRI>80
LED-FR-Wannenl. 30150.47.4 IP66 27-47,5W, 4440-7460lm, 4000K PC opal, 1450x98x91 mm, CRI>80

Width: 98 mm, Length: 1450 mm, Colour temperature: 4000 K, Max. system power: 47 W, Rated luminous flux according to IEC 62722-2- 1: 7460 lm

Product-Nr.: 30105255-1MW

Width:

98 mm

Length:

1450 mm

Colour temperature:

4000 K

Max. system power:

47 W

Rated luminous flux according to IEC 62722-2- 1:

7460 lm

Price only for registered users

Log in
To product
LED FR-Wannenl. 30150.82.4 IP66 82W, 14220lm, 4000K, CRI>80 PC opal, 1450x98x91mm
LED FR-Wannenl. 30150.82.4 IP66 82W, 14220lm, 4000K, CRI>80 PC opal, 1450x98x91mm

Width: 98 mm, Length: 1450 mm, Colour temperature: 4000 K, Max. system power: 82 W, Rated luminous flux according to IEC 62722-2- 1: 14220 lm

Product-Nr.: 30105210

Width:

98 mm

Length:

1450 mm

Colour temperature:

4000 K

Max. system power:

82 W

Rated luminous flux according to IEC 62722-2- 1:

14220 lm

Price only for registered users

Log in
To product
LED FR-Wannenl. 30150.25.4 IP66 25W, 3890lm, 4000K, CRI>80 PC opal, 1450x98x91mm
LED FR-Wannenl. 30150.25.4 IP66 25W, 3890lm, 4000K, CRI>80 PC opal, 1450x98x91mm

Width: 98 mm, Length: 1450 mm, Colour temperature: 4000 K, Max. system power: 25 W, Rated luminous flux according to IEC 62722-2- 1: 3890 lm

Product-Nr.: 30105253-1

Width:

98 mm

Length:

1450 mm

Colour temperature:

4000 K

Max. system power:

25 W

Rated luminous flux according to IEC 62722-2- 1:

3890 lm

Price only for registered users

Log in
To product
LED-FR-Wannenl. 30060.15.4 IP66 9-15W, 1290-2190lm, 4000K PC opal, 610x98x91 mm, CRI>80
LED-FR-Wannenl. 30060.15.4 IP66 9-15W, 1290-2190lm, 4000K PC opal, 610x98x91 mm, CRI>80

Width: 98 mm, Length: 610 mm, Colour temperature: 4000 K, Max. system power: 15 W, Rated luminous flux according to IEC 62722-2- 1: 2190 lm

Product-Nr.: 30105247-1MW

Width:

98 mm

Length:

610 mm

Colour temperature:

4000 K

Max. system power:

15 W

Rated luminous flux according to IEC 62722-2- 1:

2190 lm

Price only for registered users

Log in
To product
LED-FR-Wannenl. 30120.38.4 IP66 22-38,5W, 3600-6050lm, 4000K PC opal, 1170x98x91 mm, CRI>80
LED-FR-Wannenl. 30120.38.4 IP66 22-38,5W, 3600-6050lm, 4000K PC opal, 1170x98x91 mm, CRI>80

Width: 98 mm, Length: 1170 mm, Colour temperature: 4000 K, Max. system power: 38 W, Rated luminous flux according to IEC 62722-2- 1: 6050 lm

Product-Nr.: 30105251-1MW

Width:

98 mm

Length:

1170 mm

Colour temperature:

4000 K

Max. system power:

38 W

Rated luminous flux according to IEC 62722-2- 1:

6050 lm

Price only for registered users

Log in
To product
LED FR-Wannenl. 30120.20.4 IP66 20W, 3030lm, 4000K PC opal, 1170x98x91mm, CRI>80
LED FR-Wannenl. 30120.20.4 IP66 20W, 3030lm, 4000K PC opal, 1170x98x91mm, CRI>80

Width: 98 mm, Length: 1170 mm, Colour temperature: 4000 K, Max. system power: 20 W, Rated luminous flux according to IEC 62722-2- 1: 3030 lm

Product-Nr.: 30105249-1

Width:

98 mm

Length:

1170 mm

Colour temperature:

4000 K

Max. system power:

20 W

Rated luminous flux according to IEC 62722-2- 1:

3030 lm

Price only for registered users

Log in
To product
LED FR-Wannenl. 30150.63.4 IP66 63W, 9630lm, 4000K, CRI>80 PC opal, 1450x98x91mm
LED FR-Wannenl. 30150.63.4 IP66 63W, 9630lm, 4000K, CRI>80 PC opal, 1450x98x91mm

Width: 98 mm, Length: 1450 mm, Colour temperature: 4000 K, Max. system power: 63 W, Rated luminous flux according to IEC 62722-2- 1: 9630 lm

Product-Nr.: 30106798-1

Width:

98 mm

Length:

1450 mm

Colour temperature:

4000 K

Max. system power:

63 W

Rated luminous flux according to IEC 62722-2- 1:

9630 lm

Price only for registered users

Log in
To product
